🎯Why Cucumber for Integration Testing?

Cucumber enables writing human-readable feature specifications that directly map to automated tests. This approach:

• Bridges the gap: between technical and non-technical stakeholders
• Ensures requirements: are clear and testable
• Provides living documentation: that stays in sync with code
• Enables BDD workflows: for better collaboration

🏗️ Project Structure

src/test/
├── kotlin/com/github/senocak/boilerplate/
│   ├── config/
│   │   ├── CucumberTestConfig.kt          # Main test configuration
│   │   └── initializer/
│   │       └── PostgresqlInitializer.kt   # Database setup
│   └── stepdefs/
│       ├── CucumberBase.kt                # Base class with HTTP utilities
│       └── AuthSteps.kt                   # Authentication step definitions
├── resources/
│   ├── application-cucumber-test.yml      # Test-specific configuration
│   └── features/
│       └── Auth.feature                   # Gherkin feature files

💡How It Works: Complete End-to-End Example

Let’s walk through the complete flow of how Cucumber integration testing works in this project:

1️⃣Writing Feature Files

Feature files are written in Gherkin syntax to describe test scenarios in plain English. This makes them readable by non-technical stakeholders while providing structure for test automation. They are stored in src/test/resources/features/:

Feature: Feature: User Authentication
  Scenario: client makes call to POST to login
    When the client calls "/login" with username "asenocakAdmin" and password "asenocak" and cast to "com.github.senocak.boilerplate.domain.dto.UserWrapperResponse"
    Then the client receives status code of 200
    Then response has field "token"

This feature file describes a scenario where:

1. A client sends login credentials to the /login endpoint
2. We expect a 200 OK response
3. The response should contain a JWT token

2️⃣Setting Up the Test Infrastructure

The CucumberTestConfig annotation consolidates all the necessary configuration for our tests:

@Tag(value = "cucumber")
@Target(allowedTargets = \[AnnotationTarget.ANNOTATION\_CLASS, AnnotationTarget.CLASS\])
@Retention(value = AnnotationRetention.RUNTIME)
@ActiveProfiles(value = \["cucumber-test"\])
@TestClassOrder(value = ClassOrderer.OrderAnnotation::class)
@SpringBootTest(webEnvironment = WebEnvironment.RANDOM\_PORT)
@Transactional(propagation = Propagation.NOT\_SUPPORTED)
@ContextConfiguration(initializers = \[
    PostgresqlInitializer::class,
\])
@TestPropertySource(value = \["/application-cucumber-test.yml"\])
@Suite
@CucumberContextConfiguration
@IncludeEngines(value = \["cucumber"\])
@SelectClasspathResource(value = "features")
@ConfigurationParameter(key = GLUE\_PROPERTY\_NAME, value = "com.github.senocak.boilerplate.stepdefs")
@ConfigurationParameter(key = PLUGIN\_PROPERTY\_NAME, value = "pretty")
annotation class CucumberTestConfig

Key annotations:

• @ActiveProfiles(“cucumber-test”)`: Uses a dedicated test profile
• @SpringBootTest(webEnvironment = RANDOM_PORT): Starts the full application with a random port
• @ContextConfiguration(initializers = [PostgresqlInitializer::class]): Sets up a test database
• @SelectClasspathResource(“features”): Locates Gherkin feature files
• @ConfigurationParameter(key = GLUE_PROPERTY_NAME, value = “com.github.senocak.boilerplate.stepdefs”): Connects feature files to step definitions
• @CucumberContextConfiguration: Integrates Cucumber with Spring Boot
• @Transactional(propagation = NOT_SUPPORTED): Prevents transaction rollback

Database Setup with Testcontainers

The PostgresqlInitializer class creates and initializes an isolated PostgreSQL container:

@TestConfiguration
class PostgresqlInitializer: ApplicationContextInitializer<ConfigurableApplicationContext\> {
    private val postgresContainer: PostgreSQLContainer<Nothing\> = PostgreSQLContainer<Nothing\>("postgres:14").apply {
        withDatabaseName("testdb")
        withUsername("test")
        withPassword("test")
        withInitScripts("migration/V1\_\_init.sql", "migration/V2\_\_populate.sql")
        withStartupTimeout(TestConstants.CONTAINER\_WAIT\_TIMEOUT)
    }

    init {
        postgresContainer.start()
    }

    override fun initialize(configurableApplicationContext: ConfigurableApplicationContext) {
        TestPropertyValues.of(
            "spring.datasource.url=" + postgresContainer.jdbcUrl,
            "spring.datasource.username=" + postgresContainer.username,
            "spring.datasource.password=" + postgresContainer.password
        ).applyTo(configurableApplicationContext.environment)
    }
}

This provides:

• A fresh database for each test run
• Isolation from development or production environments
• Execution of migration scripts for schema and test data

3️⃣Building the Testing Foundation

The CucumberBase class provides the core HTTP testing functionality:

@CucumberTestConfig
open class CucumberBase {
    @LocalServerPort protected var localPort: Int = 0
    @Autowired protected lateinit var objectMapper: ObjectMapper
    @Autowired protected lateinit var restTemplateBuilder: RestTemplateBuilder
    protected lateinit var restTemplate: RestTemplate
    protected lateinit var latestResponse: ResponseResults
    val headers: MutableMap<String, String> = hashMapOf("Accept" to "application/json")

    // HTTP request methods (GET, POST, PUT, DELETE)
    // Response handling and parsing
}

Key Features:

• Dynamic port injection with @LocalServerPort
• Jackson integration for JSON parsing with ObjectMapper
• RestTemplate configuration for HTTP requests
• Response caching for step-to-step data sharing
• Custom error handling with ResponseResultErrorHandler
• Request headers management

HTTP Request Methods

The base class provides methods for all HTTP verbs:

@Throws(exceptionClasses = \[IOException::class\])
fun executePost(url: String, entries: MutableMap<String, Any>, classToCast: Class<\*>) {
    headers.put("Content-Type", "application/json")
    val requestCallback = HeaderSettingRequestCallback(requestHeaders = headers)
    requestCallback.setBody(JSONObject(entries).toString())
    val errorHandler = ResponseResultErrorHandler()
    restTemplate.setErrorHandler(errorHandler)
    latestResponse = restTemplate.execute(url, HttpMethod.POST, requestCallback,
        { response: ClientHttpResponse ->
            when {
                errorHandler.hadError -> errorHandler.results
                else -> ResponseResults(theResponse = response, classToCast = classToCast)
            }
        }) ?: throw IOException("Response was null for URL: $url")
}

Like above the get request method, other methods can be implemented straight-forward. These methods:

• Set appropriate headers
• Marshal request bodies to JSON
• Handle error responses
• Parse and store the response for assertions

Custom Error Handling

This captures both successful and error responses for comprehensive testing.

class ResponseResultErrorHandler: ResponseErrorHandler {
    var results: ResponseResults? = null
    var hadError = false

    override fun hasError(response: ClientHttpResponse): Boolean {
        hadError = response.statusCode.value() >= 500
        return hadError
    }
}

Custom Response Handling

The ResponseResults class captures and processes HTTP responses:

class ResponseResults internal constructor(
    val theResponse: ClientHttpResponse,
    val classToCast: Class<\*>? = null,
) {
    var body: String = toString(inputStream = theResponse.body)

    private fun toString(inputStream: InputStream): String {
        val reader = BufferedReader(inputStream.reader())
        val content = StringBuilder()
        try {
            var line = reader.readLine()
            while (line != null) {
                content.append(line)
                line = reader.readLine()
            }
        } finally {
            reader.close()
        }
        return content.toString()
    }
}

This class:

• Stores the raw HTTP response
• Reads the response body into a string
• Optionally casts the response to a specific class for type-safe assertions

4️⃣Implementing Step Definitions

Step definitions connect the Gherkin language in feature files to executable Kotlin code:

class AuthSteps: CucumberBase() {
    @Before
    fun setup() {
        restTemplate = restTemplateBuilder.rootUri("http://localhost:$localPort/api/v1/auth").build()
    }

    @Then(value = "the client calls {string} with username {string} and password {string} and cast to {string}")
    fun theClientCallsWithCredentialsAndCastsToClass(url: String, username: String, password: String, classToCast: String) {
        executePost(
            url = url,
            entries = mutableMapOf("username" to username, "password" to password),
            classToCast = Class.forName(classToCast) as Class<\*>
        )
    }

    @Then(value = "^the client receives status code of (\\\\d+)$")
    fun theClientReceivesStatusCode(statusCode: Int) {
        val currentStatusCode: HttpStatusCode = latestResponse.theResponse.statusCode
        assertEquals(expected = statusCode.toLong(), actual = currentStatusCode.value().toLong())
    }

    @Then(value = "response has field {string}")
    fun responseHasField(field: String) {
        val readTree = objectMapper.readTree(latestResponse.body)
        assertTrue { readTree.get(field) != null }
    }
}

Key aspects of step definitions:

• Dynamic base URI: construction using injected port
• @Before hook: configures the test environment
• Parameterized step patterns: with regex capture groups
• Method implementation: that executes HTTP requests
• Assertions: validate response codes and content
• Type-safe casting: for response objects

5️⃣Test Execution Flow Visualization

Here’s a diagram illustrating the flow of test execution:

┌────────────────┐     ┌─────────────────┐     ┌───────────────────┐
│                │     │                 │     │                   │
│  Auth.feature  ├────▶│  AuthSteps.kt   ├────▶│   CucumberBase    │
│                │     │                 │     │                   │
└────────────────┘     └─────────────────┘     └─────────┬─────────┘
                                                         │
┌────────────────┐     ┌─────────────────┐     ┌─────────▼─────────┐
│                │     │                 │     │                   │
│ Spring Context │◀────┤ PostgreSQL      │◀────┤   REST Template   │
│                │     │ (Testcontainers)│     │                   │
└────────────────┘     └─────────────────┘     └───────────────────

🔧Gradle Setup for Testing

The build.gradle.kts file includes specific configurations for running Cucumber tests:

dependencies {
    // Other dependencies...
    testImplementation("org.junit.platform:junit-platform-suite")
    testImplementation("io.cucumber:cucumber-java:7.23.0")
    testImplementation("io.cucumber:cucumber-junit-platform-engine:7.23.0")
    testImplementation("io.cucumber:cucumber-spring:7.23.0")
    testImplementation("org.testcontainers:testcontainers:1.21.3")
    testImplementation("org.testcontainers:junit-jupiter:1.21.3")
    testImplementation("org.testcontainers:postgresql:1.21.3")
}

tasks.withType<Test> {
    systemProperty("cucumber.junit-platform.naming-strategy", "long")
    // ...
}

tasks.register<Test>(name = "integrationTest") {
    description = "Runs the integration tests"
    group = "Verification"
    include("\*\*/\*IT.\*")
    useJUnitPlatform()
}

Key configuration elements

• Cucumber dependencies for BDD testing
• JUnit platform for integration
• Testcontainers for database isolation
• Task configuration for specific test types

🧪Command Line Execution

# Run all tests including Cucumber

./gradlew test

# Run only integration tests

./gradlew integrationTest

# Skip specific test types

./gradlew test -PskipTests=integration
./gradlew test -Dspring.profiles.active=cucumber-test

# Skip all tests

./gradlew test -PskipTests=all

Debugging Tips

• View Cucumber output with the pretty formatter:

@ConfigurationParameter(key = PLUGIN\_PROPERTY\_NAME, value = "pretty")

• Inspect HTTP requests/responses by adding debug logs:

private val log: Logger by logger()
log.debug("Request body: ${requestCallback.body}")

• Use explicit assertions** for clear failure messages:

assertEquals(
    expected = statusCode.toLong(),
    actual = currentStatusCode.value().toLong(),
    message = "Expected status ${statusCode} but got ${currentStatusCode.value()}"
)

🔍Execution Flow

1. Container Startup: PostgreSQL container initializes
2. Spring Context: Application starts with random port
3. Feature Loading: Gherkin files are parsed
4. Step Execution: HTTP requests hit live application
5. Response Validation: JSON responses are verified
6. Cleanup: Container and context shutdown

🎯Best Practices Demonstrated

Separation of Concerns:

• Base class handles HTTP mechanics
• Step definitions focus on business logic
• Feature files contain readable scenarios

Reusable Components

• Generic HTTP methods support multiple endpoints
• Parameterized steps reduce code duplication
• Response objects enable cross-step validation

Robust Error Handling

• Custom error handler captures failures
• Response details preserved for debugging
• Both success and error paths testable

Database Isolation

• Testcontainers provide clean database state
• No test pollution between scenarios
• Realistic database behavior

Configuration Management

• Profile-specific settings (cucumber-test)
• Flyway disabled for faster startup
• Environment-specific properties

🎉Benefits of This Architecture

Maintainable Test Suite

• Adding new scenarios is straightforward
• Step definitions are organized by domain
• Common patterns are abstracted

Clean Separation of Concerns

• Feature files describe business requirements
• Step definitions implement test logic
• Base class handles technical HTTP details
• Scalable components

Reliable

• Isolated database state prevents flaky tests

Reusable Components

• HTTP client functionality is centralized
• Common assertions are abstracted
• Setup code is shared across scenarios
• Fast feedback loop with Testcontainers

Readable

• Business-friendly Gherkin scenarios

Realistic Testing Environment

• Tests run against a full Spring context
• Database interactions use real PostgreSQL
• HTTP requests hit actual endpoints

🚦Conclusion

This Cucumber integration testing architecture provides a powerful and solid foundation for BDD-style integration testing in a Spring Boot. By combining the readability of Gherkin with the power of Spring’s testing framework and the isolation of Testcontainers, you can build a comprehensive, maintainable test suite that validates your application’s behavior from end to end.

The approach demonstrated here ensures that your tests:

• Are readable by all stakeholders
• Provide living documentation
• Test realistic scenarios
• Maintain isolation between test runs
• Can be extended to cover new features

By adopting these patterns, you can build confidence in your application’s behavior while creating a valuable resource for understanding its requirements and functionality.

🔮What’s Next?

Now that you have a solid foundation for Cucumber integration testing with Spring Boot, here are some ways to enhance your testing suite:

Expand Test Coverage

• Add feature files for other endpoints in your API
• Test edge cases and error scenarios
• Create scenarios for complex business workflows

Advanced Cucumber Features

• Use Scenario Outlines for data-driven testing:

Scenario Outline: Login with various credentials
  When the client calls "/login" with username "<username>" and password "<password>"
  Then the client receives status code of <statusCode>

  Examples:
    | username      | password   | statusCode |
    | validUser     | validPass  | 200        |
    | invalidUser   | validPass  | 401        |
    | validUser     | wrongPass  | 401        |

• Add Background steps for common setup:

Feature: User management

  Background:
    Given the database contains a user with username "admin"

  Scenario: Get user details
    When the client authenticates as "admin"
    And the client calls "/users/me"
    Then the client receives status code of 200

Enhance Reporting

• Add Cucumber HTML reports:

@ConfigurationParameter(
    key = PLUGIN\_PROPERTY\_NAME,
    value = "pretty, html:build/reports/cucumber/report.html"
)

• Integrate with test reporting tools like Allure:

dependencies {
    // existing dependencies...
    testImplementation("io.qameta.allure:allure-cucumber7-jvm:2.24.0")
}

Parallel Test Execution

• Configure Cucumber for parallel execution:

@ConfigurationParameter(
    key = "cucumber.execution.parallel.enabled",
    value = "true"
)
@ConfigurationParameter(
    key = "cucumber.execution.parallel.config.strategy",
    value = "dynamic"
)

CI/CD Integration

• Add GitHub Actions workflow for automated testing:

name: Cucumber Tests
on: \[push, pull\_request\]
jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      \- uses: actions/checkout@v3
      \- name: Set up JDK 17
        uses: actions/setup-java@v3
        with:
          java-version: '17'
          distribution: 'temurin'
      \- name: Run tests
        run: ./gradlew integrationTest
      \- name: Publish Test Report
        uses: mikepenz/action-junit-report@v3
        if: always()
        with:
          report\_paths: 'build/test-results/test/TEST-\*.xml'

Custom Step Libraries

• Create domain-specific step libraries for different parts of your application:

class UserManagementSteps: CucumberBase() {
    // User-specific step definitions
}

class PaymentSteps: CucumberBase() {
    // Payment-specific step definitions
}

Visual Testing Integration

• Add screenshot capture for UI tests:

@Then("take screenshot")
fun takeScreenshot() {
    // Screenshot logic for Selenium or similar
}

By implementing these enhancements, you’ll create an even more robust and maintainable testing framework that scales with your application’s complexity.

🔗Additional Resources

• Cucumber Documentation
• Spring Boot Testing Guide
• Testcontainers for Java
• JUnit 5 User Guide

🖥️ Demo

This guide demonstrates how to implement robust Behavior-Driven Development (BDD) integration tests using Cucumber in a Spring Boot. The setup leverages Testcontainers for database isolation and provides a clean, maintainable testing architecture.

Full code example can be found in github
